Sitex CVS128 8.4in Color LCD Sounder With Out Transducer
- Dual-Frequency (50/200kHz) operation with digital signal processor (DSP) for a clearer image that enhances fish targets in shallow and deep depths, plus auto function for the most reliable setting and best performance
- Boasts 1000 or 600 watts with 8 ranges from 10-3600'.
- Exclusive Sona-Tone identifies what's under your boat with different sounds for fish and schools of fish.
- Stores up to 10 screen images in built-in memory for recall later. RGB output for connecting optional external VGA monitor.
- High-speed pulse rate transmission of 5000 times per minute for enchanced shallow water detection.
- Other features: anti-reflective display, easy operation, auto fishing/cruising modes, audio/visual alarms, Fishing Hot Spot function leads you back to your favorite fishing hot spots with GPS sensor input, IPX5 waterproof rating, over-head and built-in flushing mounting. 10.8~31.2 VDC
| SI-TEX CVS-128 Digital Echo Sounder- Specifications | |
| Display | 8.4" TFT Color LCD (640 x 480 pixels) |
| Display Colors | 8, 16, 64 or monochrome |
| Power Requirments | 10.8 ~31.2V DC. |
| Power Consumption | 25w or less at 12V DC |
| Operating Frequency | Dual Frequency 50/200 kHz |
| Output Power | 600W/1000W |
| Background Colors | Blue, dark blue, black, white, nighttime and 5 other colors |
| Display Modes | High frequency, Low frequency, Dual frequency, Zoom image, Nav mode, A-Scope (can be added all above modes), left and right divided |
| Zoom Modes | Bottom lock, Bottom discrimination, Bottom zoom, Zoom, Sea Bottom, Partial zoom |
| Depth Ranges* | 8 ranges from 10 to 3600' |
| Zoom Ranges | 10 to 650' (23 steps) |
| Audible Alarm | Fish, bottom, depth, temperature**, speed ***, arrival****, XTE**** |
| Image Speed | 9 levels plus stop |
| Image Shift | Auto or Manual (0 to 1000') |
| Auto Functions | Depth range, Shift and Gain |
| Languages | English, Spanish, French, Greek, Italian, Japanese, Korean, Chinese, Thai |
| Distance Unit | ft, m, fm, 1, FM |
| Input Format | NMEA0183 (GGA, GLL, ZDA, VTG, RMC, MTW, VHW, MWV, HDT) |
| Output Format | NMEA0183 (DBT, DPT, GGA, GLL, MTW, RMC, TLL, VHW, VTG, ZDA, HDT, MWV) |
| Other Functions | Interference rejection, Color rejection, Depth marker (VRM), Event Memory, Panel illumination, Draft adjustment, Temperature correct, Boat speed correct, White line, Sona-Tone?, Power reduction, Built-in simulator, Noise rejection, Simple Plotter |
| Waterproof Rating | IPX 5 |
| Operating Temperature | 5 to 131 F (-15 to +55 C) |
| Case Size/Weight | 9.5"W x 9.5"H x 4.5"D, 7.2 lbs |
